SPESIFIKASI
Max pressure : 102 Psi *Shut off
Straight stream reach : 37 meter
Laju aliran (flow) : 440 L/menit
Waktu hisap : 19.02 detik
ENGINE
| Merk /
Model |
Honda / GX270 |
| Engine type |
4-stroke, overhead valve single cylinder, inclined by 25° |
| Displacement |
270 cm³ |
| Bore and stroke |
77.0 × 58.0 mm |
| Compression ratio |
8.5:1 |
| Gross power (SAE J1995) |
6.6 kW (9 HP)/3600rpm |
| Net power (SAE J1349)* |
6.3 kW (8.4 HP)/3600 min-1 rpm |
| Max. Net torque (SAE J1349)* |
19.1 N.m/2500 min-1 rpm |
| Starting system |
Recoil starter |
| Ignition system |
BPR6ES (NGK) / W20EPR-U (DENSO) |
| Spark plug |
CDI type magneto ignition |
| Air cleaner |
Dual element type |
| Oil capacity |
1.1 Liters, SAE 10W-30 (API SE or Later) |
| Fuel tank capacity |
5.3 liters |
| Recommended fuel |
Unlead 86 octane or higher |
|
|
|
|
| PUMP |
|
| Type |
Single stage centrifugal, direct drive |
| Body & diffusers |
Anodized resistant aluminium |
| Impeller |
Anodized resistant aluminium |
| Pump shaft |
Stainless steel |
| Pump seal |
Heat resistant rotary mechanical seal |
