SPESIFIKASI
Max pressure : 87 Psi *Shut off
Straight stream reach : 30 meter
Laju aliran (flow) : 230 L/menit
| ENGINE |
|
| Merk / Model |
Honda / GXV160 |
| Engine type |
Air-cooled 4-stroke OHV, petrol engine, vertical saft, cast iron sleeve |
|
163 cm3 |
| Displacement |
68 X 45 mm |
| Bore x stroke |
3.2 kW (4.3 HP)/3,600rpm |
| Net power output* |
2.0 kW (2.7 HP)/3,000rpm |
| Cont. rate power |
9.6 Nm / 0.98 kgfm)/2,500rpm |
| Net torque |
8.0:1 |
| Compression ratio |
Transistorized |
| Ignition system |
Recoil starter |
| Starting system |
Centrifugal mechanical |
| Governor system |
Dual element |
| Air cleaner |
0.65 liter |
| Oil capacity |
1.4 liter |
| Fuel tank capacity |
Unlead 86 octane or higher |
| Recommended fuel |
Unlead 86 octane or higher |
|
|
| PUMP |
|
| Type |
Single stage centrifugal, direct drive |
| Body & diffusers |
Anodized resistant aluminium |
| Impeller |
Anodized resistant aluminium |
| Pump shaft |
Stainless steel |
| Pump seal |
Heat resistant rotary mechanical seal |
