SPESIFIKASI
Max pressure : 102 Psi *Shut off
Straight stream reach : 37 meter
Laju aliran (flow) : 510 L/menit
| ENGINE |
|
| Merk / Model |
Honda / GXV390 |
| Engine type |
Air-cooled 4-stroke OHV, petrol engine, vertical saft, cast iron sleeve |
| Displacement |
389 cm3 |
| Bore x stroke |
88 X 64 mm |
| Net power output* |
7.6 kW (10.2 HP)/3,600rpm |
| Cont. rate power |
5.2 kW (7.0 HP)/3,000rpm |
| Net torque |
24.2 Nm / 2.47 kgfm)/2,500rpm |
| Compression ratio |
7.7:1 |
| Ignition system |
Transistorized |
| Starting system |
Recoil starter |
| Governor system |
Centrifugal mechanical |
| Air cleaner |
Dual element |
| Oil capacity |
1.1 liter |
| Fuel tank capacity |
2.1 liter |
| Recommended fuel |
Unlead 86 octane or higher |
|
|
| PUMP |
|
| Type |
Single stage centrifugal, direct drive |
| Body & diffusers |
Anodized resistant aluminium |
| Impeller |
Anodized resistant aluminium |
| Pump shaft |
Stainless steel |
| Pump seal |
Heat resistant rotary mechanical seal |
