SPESIFIKASI
Max pressure : 116 Psi *Shut off
Straight stream reach : 40 meter
Laju aliran (flow) : 620 L/menit
Waktu hisap : 13.03 detik
| ENGINE |
|
| Merk / Model |
Honda / GX690 |
| Engine type |
4-stroke, overhead valve 90° V-twin cylinder |
| Displacement |
688 cm³ |
| Bore and stroke |
78.0 x 72 mm |
| Compression ratio |
9.3 |
| Gross power (SAE J1995) |
18.75 kW (25.0 HP)/3600rpm |
| Net power (SAE J1349)* |
16.5 kW (22.1 HP)/3600 min-1 rpm |
| Max. Net torque (SAE J1349)* |
48.3 N.m (4.93 kgf-m)/2,500 rpm |
| Starting system |
Electric starter |
| Ignition system |
CDI type Magneto ignition |
| Spark plug |
ZFR5F (NGK) |
| Air cleaner |
Dual type |
| Oil capacity |
1.5 Liters, 1.7 Liters (With oil filter replacement), SAE 10W-30 (API SE
or later) |
| Fuel tank capacity |
11 liters |
| Recommended fuel |
Unleaded Gasoline (Octane 86 or higher) |
|
|
| PUMP |
|
| Type |
Single stage centrifugal, direct drive |
| Body & diffusers |
Anodized resistant aluminium |
| Impeller |
Anodized resistant aluminium |
| Pump shaft |
Stainless steel |
| Pump seal |
Heat resistant rotary mechanical seal |
